Gruvlok fittings are available through 24" nominal pipe size in a variety of styles. Use the Fitting Size Table to convert nominal pipe size to corresponding pipe O.D.
These fittings are designed to provide minimum pressure drop and uniform strength.
Depending on styles and size, Gruvlok fittings are provided in various materials including ductile iron, forged steel or fabricated steel.
Pressure ratings of Gruvlok standard fittings conform to those of Fig. 7001 Gruvlok coupling.
1 - 25 of 136 | Results Per Page | View | Unit of Measure
1 2 3 4 5 »
Request Information Compare Items Add to CAD Cart

Item #

BIM

Nominal Size

Coatings

Flow Data

Weight

N/A Revit Icon (for items table) N/A 2x2x1 N/A Rust inhibiting paint Color: ORANGE N/A 4.4 ft N/A 2.6 lb
N/A Revit Icon (for items table) N/A 2x2x1 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 4.4 ft N/A 2.6 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/2 N/A Rust inhibiting paint Color: ORANGE N/A 6.7 ft N/A 2.70 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/2 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 6.7 ft N/A 2.70 lb
N/A Revit Icon (for items table) N/A 3x3x1 N/A Rust inhibiting paint Color: ORANGE N/A 4.4 ft N/A 7.00 lb
N/A Revit Icon (for items table) N/A 3x3x1 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 4.4 ft N/A 7.00 lb
N/A Revit Icon (for items table) N/A 5X5X4 N/A Rust inhibiting paint Color: ORANGE N/A 16.8 ft N/A 17.9 lb
N/A Revit Icon (for items table) N/A 5X5X4 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 16.8 ft N/A 17.9 lb
N/A Revit Icon (for items table) N/A 6X6X4 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 16.8 ft N/A 26.5 lb
N/A Revit Icon (for items table) N/A 6X6X5 N/A Rust inhibiting paint Color: ORANGE N/A 21.0 ft N/A 28.0 lb
N/A Revit Icon (for items table) N/A 6X6X5 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 21.0 ft N/A 28.0 lb
N/A Revit Icon (for items table) N/A 8X8X4 N/A Rust inhibiting paint Color: ORANGE N/A 16.8 ft N/A 50.0 lb
N/A Revit Icon (for items table) N/A 10X10X6 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 25.3 ft N/A 55.0 lb
N/A Revit Icon (for items table) N/A 10X10X8 N/A Rust inhibiting paint Color: ORANGE N/A 33.3 ft N/A 64.7 lb
N/A Revit Icon (for items table) N/A 10X10X8 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 33.3 ft N/A 64.7 lb
N/A Revit Icon (for items table) N/A 14x14x12 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 50.0 ft N/A 117.0 lb
N/A Revit Icon (for items table) N/A 2x2x3/4 N/A Rust inhibiting paint Color: ORANGE N/A 8.6 ft N/A 1.6 lb
N/A Revit Icon (for items table) N/A 2x2x3/4 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 8.6 ft N/A 1.6 lb
N/A Revit Icon (for items table) N/A 2x2x1 N/A Rust inhibiting paint Color: ORANGE N/A 8.6 ft N/A 2.6 lb
N/A Revit Icon (for items table) N/A 2x2x1 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 8.6 ft N/A 2.6 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/4 N/A Rust inhibiting paint Color: ORANGE N/A 8.6 ft N/A 1.7 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/4 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 8.6 ft N/A 1.7 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/2 N/A Rust inhibiting paint Color: ORANGE N/A 8.6 ft N/A 2.70 lb
N/A Revit Icon (for items table) N/A 2x2x1 1/2 N/A Hot Dipped Zinc Galvanized conforming to ASTM A-153 N/A 8.6 ft N/A 2.70 lb
N/A Revit Icon (for items table) N/A 2 1/2x2 1/2x1 N/A Rust inhibiting paint Color: ORANGE N/A 10.3 ft N/A 4.1 lb
