  • Fig-436A
Service: For the support of piping where horizontal movement resulting from expansion and contraction takes place and where a low coefficient of friction is desired.
Maximum Load: As indicated at 70° F see page 141 for rating factor at higher temperatures.
Features:
  • No lubrication required.
  • Designed to minimize heat loss.
  • Allows up to 3" of insulation on Types 1, 2, 4 & 5 and up to 2 1/2" of insulation on Types 3 & 6.
  • Allows up to 10" travel standard
  • Weld in place design.
Ordering: Specify figure number, type, name, finish and any other option desired.
1 - 25 of 64 | Results Per Page | View | Unit of Measure
1 2 3
Request Information Compare Items Search by Specification Add to CAD Cart

Item #

CAD

Pipe Size

Finish

Weight

N/A CAD Icon (for items table) N/A N/A Plain N/A 7.00 lb
N/A CAD Icon (for items table) N/A N/A Galvanized N/A 7.00 lb
N/A N/A 2 in N/A Plain N/A 7.139 lb
N/A N/A 3 in N/A Plain N/A 7.379 lb
N/A N/A 4 in N/A Plain N/A 7.499 lb
N/A N/A 5 in N/A Plain N/A 7.879 lb
N/A N/A 6 in N/A Plain N/A 8.119 lb
N/A N/A 8 in N/A Plain N/A 8.579 lb
N/A N/A 10 in N/A Plain N/A 9.179 lb
N/A N/A 12 in N/A Plain N/A 9.779 lb
N/A N/A 14 in N/A Plain N/A 9.979 lb
N/A N/A 16 in N/A Plain N/A 10.379 lb
N/A N/A 18 in N/A Plain N/A 10.979 lb
N/A N/A 20 in N/A Plain N/A 11.379 lb
N/A N/A 24 in N/A Plain N/A 12.179 lb
N/A N/A 2 in N/A Galvanized N/A 7.139 lb
N/A N/A 3 in N/A Galvanized N/A 7.379 lb
N/A N/A 4 in N/A Galvanized N/A 7.499 lb
N/A N/A 5 in N/A Galvanized N/A 7.879 lb
N/A N/A 6 in N/A Galvanized N/A 8.119 lb
N/A N/A 8 in N/A Galvanized N/A 8.579 lb
N/A N/A 10 in N/A Galvanized N/A 9.179 lb
N/A N/A 12 in N/A Galvanized N/A 9.779 lb
N/A N/A 14 in N/A Galvanized N/A 9.979 lb
N/A N/A 16 in N/A Galvanized N/A 10.379 lb
